Virtual Lab: Quantum-dot Cellular Automata - Logic Gates
University of Virginia


© 2003-Present, John C. Bean

AND gate:

Majority gates can also be used to make AND gates.

An AND gate also has two inputs. Its output becomes "1" only if both the first and second inputs are "1."
