Virtual Lab: Quantum-dot Cellular Automata - Memory Cells
 University of Virginia


© 2003-Present, John C. Bean

In addition to wires that send a logic signal from one point to another, at times circuits need to divide one signal and send it on to multiple places. This is called "fanout".

QCA cells can be arranged in this X-like pattern to accomplish fanout.
