Virtual Lab: Two Bulbs in Series
 University of Virginia


© 2003-Present, John C. Bean

Connecting the second lamp increases the resistance of the circuit reducing the brightness of both lamps.

The voltage drop across the first lamp becomes only 0.75 V.
