SCALPEL stands for Scattering with Angular Limitation Projection Electron beam Lithography. It is a new technique for creating patterns with extremely small features in microelectronic circuits. Electrons are projected onto a "mask." Those passing straight through the mask transfer the image of the mask to the wafer. This process is analogous to the way a viewgraph projector works.

To start this tour, click the "Next Scene" button at the bottom of this page.

To navigate further, use the buttons at the bottom of the page. (You can also move between scenes by using your keyboard’s arrows, and then play movies by clicking enter/return).

You can jump ahead by clicking an icon.

To see related webpages on this website, click the "Related Pages" button.
